| Business Type | Manufacturer, Exporter, Supplier, Trader |
| Brand Name | Mukta Instuments |
| Color | Dark Blue |
| Accuracy | HLD ±0.5% (800 HLD) |
| Click to view more | |
Product Details
Country of Origin
India
Repeatability Value
HLD 0.8% (800 HLD)
Display
128 × 64 OLED display
Power Supply
Rechargeable lithium battery
Continuous Working Time
~10 hours
Dimensions (L × W × H)
148 × 40 × 30mm (host)
Weight
0.3kg (host)
1. Measurement Range
• Hardness Scales:
◦ HLD: 170 - 960
◦ HRC: 17.9 - 69.5
◦ HB: 19 - 683
◦ HV: 80 - 1042
◦ HS: 30.6 - 102.6
◦ HRA: 59.1 - 88
◦ HRB: 13.5 - 101.7
\\n
2. Impact Directions: Up, down, horizontal, slanting up, slanting down
3. Measuring Materials
• Steel and cast steel
• Alloy tool steel
• Stainless steel
• Gray cast iron
• Nodular cast iron
• Cast aluminum alloy
• Copper-zinc alloys (brass)
• Copper-tin alloy (bronze)
• Pure copper
• Forged steel
4. Standards Compliance
• ASTM A956
• DIN 50156-1
• GB/T 17394-1998
