Control Panels
Leading Manufacturers, Exporters, Wholesaler and Trader of 32 Channel Control Panel, Sound Alarms 8 Channel Control Panel and Sound Alarms 16 Channel Control Panel from Bangalore.
| Business Type | Manufacturer, Exporter, Supplier, Trader |
| Brand Name | Mukta Instruments |
| Color | Grey |
| Display Type | Digital |
| Country of Origin | India |
| Dimensions | 464 × 280 × 100 mm |
| Display | 7-inch 800 × 480 touch color screen |
| Display Mode | Adaptive to channel number, with automatic page turning |
| Inspection Interval | 200 ms (data collection time interval) |
| Communication Rate | 9600 bps (customizable) |
| Transmission Distance | ≤1000 meters (dependent on cable quality) |
| Power Input | AC 220V, 50Hz |
| Power Output | DC 24V, 0.25A/channel |
| Working Temperature | -10℃ to 50℃ |
| Working Humidity | ≤95% RH, no condensation |
| Product Weight | 4.7 kg |
| Technical Parameters | Wall-mounted configuration |
| Installation Method | Wall-mounted |
| Business Type | Manufacturer, Exporter, Supplier, Trader |
| Brand Name | Mukta Instruments |
| Color | Creamy |
| Country of Origin | India |
| Detector Type | Fixed Gas Detector |
| Dimensions (L × W × H) | 30.5 cm × 21 cm × 9 cm |
| Humidity | <95% RH |
| Power Supply | Supplies 24v Dc to Connected Sensors |
| Signal Collection | Collects 4–20 Ma Input Signals from Sensors |
| Data Analysis | Analyses and Displays the Received Data |
| Alarm Setting | Configures Alarm Thresholds Based On Sensor Data |
| No Of Channel | 8 Channel |
| Business Type | Manufacturer, Exporter, Supplier, Trader |
| Weight | 4.6 Kg |
| Country of Origin | India |
| Color | Grey |
| Brand Name | Mukta Instruments |
| Display | High-light Led Nixie Tube Display |
| Working Voltage | 220V AC, 50Hz |
| Operating Temperature | 20°C to 50°C |
| Humidity | Up to 95% RH |
| Alarm Method | Two-level Light and Sound Alarms |
| Input Signal | 4–20 Ma |
| Output Signal | 4–20 Ma (optional) |
| Dimensions | 48 cm × 27 cm × 9 cm |
1. Detection Principle
• Supplies 24V DC to connected sensors
• Collects and analyses 4–20 mA input signals
• Displays data and sets alarm thresholds
